Total power | 850 W |
Peak power | 900 W |
AC input voltage | 100 – 240 V |
AC input frequency | 50/60 Hz |
Maximum input current (@110V) | 12 A |
Maximum input current (@220V) | 6 A |
Power factor | 0.98 |
Power Factor Correction (PFC) type | Active |
Number of +12V rail(s) | 1 |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 850 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 22 A |
Max output current (+12V1) | 70.9 A |
Max output current (+5V) | 22 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
Hold time | 17.34 ms |
Efficiency | 90.5% |
Power protection features | Over currentOver powerOver voltageOverheatingShort circuitSurge & inrush protection (SIP)Under voltage |
Motherboard power connector | 20+4 pin ATX |
Motherboard power cable length | 55 cm |
Number of SATA power connectors | 6 |
SATA power cable length | 500 mm650800950 mmFold |
Peripheral (Molex) power connectors (4-pin) | 1 |
Peripheral (Molex) power cable length | 800 |
PCI Express power connectors (6+2 pin) | 3 |
PCI Express power connectors (12-pin) | 1 |
PCI Express power cable length | 60 cm |
CPU power connector (4+4 pin) | Yes |
CPU power cable length | 60 cm |
Cabling type | Non-Modular |
80 PLUS certification | 80 PLUS Gold |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX version | 3.1 |
EPS version | 2.92 |
Noise level | 25.1 dB |
Bearing technology | Rifle |
Mean time between failures (MTBF) | 100000 h |
Product colour | Black |
Cooling type | Active |
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
On/off switch | Yes |
Cables included | AC |
Cable tie(s) included | Yes |
Width | 86 mm |
Depth | 160 mm |
Height | 150 mm |
Weight | 2.7 kg |
