Processor
Number of processors installed | 1 |
---|---|
Processor boost frequency | 5.7 GHz |
Performance cores | 8 |
Efficient cores | 16 |
Performance-core base frequency | 3.7 GHz |
Efficient-core base frequency | 3.2 GHz |
Processor base power | 125 W |
Maximum turbo power | 250 W |
Processor generation | Intel Core Ultra (Series 2) |
Performance-core Max Turbo Frequency | 5.5 GHz |
Processor family | Intel Core Ultra 9 |
Processor frequency | 3.2 GHz |
Processor cores | 24 |
Processor model | 285K |
Processor threads | 24 |
Processor cache | 36 MB |
Processor cache type | Smart Cache |
Processor manufacturer | Intel |
Processor socket | LGA 1851 (Socket V1) |
Efficient-core Max Turbo Frequency | 4.6 GHz |
Graphics
Discrete graphics memory type | GDDR7 |
---|---|
Number of discrete graphics cards | 1 |
Graphics card HDMI ports quantity | 1 |
Graphics card DisplayPorts quantity | 3 |
Discrete GPU manufacturer | NVIDIA |
CUDA | Yes |
Discrete graphics card model | NVIDIA GeForce RTX 5090 |
NVIDIA GameWorks VR | Yes |
On-board GPU manufacturer | Intel |
On-board graphics card model | Intel Graphics |
NVIDIA G-SYNC | Yes |
Discrete graphics card memory | 32 GB |
On-board graphics card | Yes |
Discrete graphics card | Yes |
On-board graphics card family | Intel Graphics |
Memory
Memory layout (slots x size) | 2 x 32 GB |
---|---|
Memory slots | 4x DIMM |
Internal memory manufacturer | Kingston |
Maximum internal memory | 256 GB |
Internal memory | 64 GB |
Internal memory type | DDR5-SDRAM |
Memory clock speed | 6000 MHz |
Memory channels | Dual-channel |
ECC | No |
Design
Water cooling system | Yes |
---|---|
Number of 3.5" bays | 1 |
Number of 2.5" bays | 6 |
Refurbished | No |
Viewing window | Yes |
Product colour | Black |
VESA mounting | No |
Chassis type | Midi Tower |
Housing material | Metal, Plastic, Tempered glass |
RGB backlighting | Yes |
Power
Power supply input voltage | 100-240 V |
---|---|
Power supply | 1000 W |
80 PLUS certification | 80 PLUS Gold |
Weight & dimensions
Weight | 12 kg |
---|---|
Width | 228 mm |
Depth | 489 mm |
Height | 486 mm |
Network
Bluetooth version | 5.4 |
---|---|
Bluetooth | Yes |
LAN controller | Realtek RTL8126 |
Antenna type | 2×2 |
Ethernet LAN data rates | 10, 100, 1000 Mbit/s, 2500, 5000 Mbit/s |
WLAN controller manufacturer | Intel |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Wi-Fi standards | 802.11b, Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
Cabling technology | 10/100/1000Base-T(X) |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Performance
Virtual Reality (VR) ready | Yes |
---|---|
Powered by | ENDORFY |
Motherboard chipset | Intel Z890 |
Audio chip | Realtek ALC897 |
Audio output channels | 7.1 channels |
Motherboard form factor | ATX |
Product type | PC |
Fingerprint reader | No |
Market positioning | Gaming |
Packaging content
Keyboard included | No |
---|---|
Mouse included | No |
Expansion slots
PCI Express x16 (Gen 4.x) slots | 2 |
---|---|
PCI Express x1 (Gen 4.x) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
Display
Display included | No |
---|
Software
Operating system installed | No |
---|
Storage
SSD form factor | M.2 |
---|---|
NVMe | Yes |
SSD capacity | 2 TB |
Total SSDs capacity | 2 TB |
Number of SSDs installed | 1 |
SSD interface | PCI Express |
Intel® Optane™ Memory module installed | No |
Optical drive type | No |
Total storage capacity | 2 TB |
Storage media | SSD |
Card reader integrated | No |
Number of storage drives supported | 8 |
Number of storage drives installed | 1 |
M.2 SSD size | 2280 (22 x 80 mm) |
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
---|---|
Line-out | No |
Line-in | Yes |
DC-in jack | No |
S/PDIF out port | No |
DisplayPorts quantity | 4 |
Number of SATA III connectors | 4 |
Intel® Thunderbolt 4 | Yes |
Thunderbolt 4 ports quantity | 1 |
Number of front USB ports | 3 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
Combo headphone/mic port | No |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
HDMI ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
DVI port | No |
PS/2 ports quantity | 1 |
Microphone in | Yes |
Headphone outputs | 1 |
Fiber NIC port (Flex I/O) | No |
Intel® Thunderbolt 5 | No |
Number of rear USB ports | 8 |
Number of front audio ports | 2 |
Number of rear audio ports | 3 |
Neural processor unit (NPU)
Total processor performance up to | 36 TOPs |
---|---|
GPU performance up to | 8 TOPs |
Neural processor unit (NPU) | Intel AI Boost |
NPU performance up to | 13 TOPs |
Sparsity support | Yes |
Windows Studio effects support | Yes |
AI datatype support on NPU | Int8 |
AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, Windows ML, WebNN |
