Processor
Processor manufacturers
The manufacturer of the processor.
Intel
Processor family
A family of processors is a group of processors produced by the same company over a short period of time, e.g. Intel Pentium processors.
Intel® Core™ i9
Processor generation
Intel Core i9-14xxx
Processor
The model number for the processor in a computer.
i9-14900K
Number of processor cores
The number of central processing units (‘cores’) in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
24
Processor Threads
32
Processor Boost Frequency
Turbo Boost is an automatic, controlled acceleration of the processor when one of the cores is overloaded.
6 GHz
Performance Cores
8
Efficient cores
16
Performance core maximum turbo frequency
5.6 GHz
Efficient core, maximum turbo frequency
4.4 GHz
Power Base Frequency of Core
3.2 GHz
Efficient base frequency of the core
2.4 GHz
Processor Cache
36 MB
Processor Cache Type
Smart Cache
Number of processors installed
Number of processors and multi-processing support for this product
1
Base Processor Performance
125 W
Maximum Turbo Performance
253 W
Memory
Storage capacity
The portion of computer memory that the CPU can access directly.
64 GB
RAM memory maximum
The maximum internal data storage available in the device.
128 GB
Internal storage type
The type of internal storage device, e.g. RAM, GDDR5.
DDR5-SDRAM
Memory layout
The slots and the amount of memory for the CPU.
2 x 32 GB
Memory card slots
Number and type of memory slots; including plug and memory module descriptions
4x DIMM
Memory clock speed
The frequency at which the memory (e.g. RAM) runs.
4800 MHz
Without ECC
Recording medium
Total storage capacity
The total amount of data that can be stored on the device.
1 TB
Storage
Used to store data, e.g. hard drive, SSD (solid-state drive).
SSD
Optical Drive Type
An optical drive uses lasers to read image discs such as CDs, DVDs, and Blu-Rays. Some types of optical drives are: CD-ROM drive, CR-RW (CD burner), DVD-ROM.
Number of Storage Drives Installed
Number of storage drives built into the device.
1
Total capacity of SSDs
1 TB
Number of SSD installed
1
SSD Storage Capacity
The data storage capacity of the solid-state drive.
1 TB
SSD Interface
The type of interface(s) that connect the solid state drive to other hardware.
PCI Express 4.0
NVMe
NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media connected via a PCI Express (PCIe) bus. NVM Express is designed as a logical device interface to take advantage of the low latency and internal parallelism of solid-state storage devices.
SSD form factor
SSD size, expressed in inches.
M.2
M.2 SSD Size
2280 (22 x 80 mm)
Integrated card reader
A card reader allows you to read and, in some cases, read data to and from a memory card.
Compatible Memory Cards
Types of memory cards that can be used with this product.
SD
Graphic
Separate graphics adapter
Separate GPU manufacturer
NVIDIA
Built-in graphics adapter
Graphics hardware that is integrated into the motherboard or CPU, as opposed to a separate graphics adapter (graphics card). On-board graphics uses CPU and RAM for graphics processing.
Separate graphics card model
A graphics adapter (often referred to as a video card) generates images for a display. A discrete graphics adapter connects to the motherboard and usually produces significantly better graphics than an integrated graphics adapter. There are different models of discrete graphics adapters.
NVIDIA RTX 2000 Ada
Separate graphics adapter memory
16 GB
Dedicated graphics memory type
GDDR6
Number of dedicated graphics cards
1
Manufacturer of the built-in GPU
Intel
On-Board Graphics Adapter Family
Intel® UHD Graphics
Built-in graphics card model
“Graphic adapter” is the hardware that produces images on a display. “On-board” means that the graphics adapter is intergrated inside the motherboard.
Intel UHD Graphics 770
Number of Graphics Adapters Mini DisplayPort Connectors
4
Network
Ethernet/LAN
For a wired connection, an Ethernet LAN interface (Local Area Network) is available.
Ethernet LAN Data Transfer Rates
The different speed levels of the Ethernet LAN connection.
10, 100, 1000 Mbps
LAN Controller
Intel® i219-LM
WIRELESS
Popular technology that allows an electronic device to exchange data wirelessly or connect wirelessly to the Internet.
Connectors and Interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-A ports
6
Connectors and Interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-A ports
2
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports
Number of USB 3.1 (3.1 Gen 2) ports with Type-C port. USB 3.1 (3.1 Gen 2) is a USB interface that supports a transfer rate of up to 10 Gbps (SuperSpeed+). The USB Type-C port has a symmetrical design architecture and is compatible with the Thunderbolt 3 interface.
1
Number of HDMI ports
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed or uncompressed digital audio data from an HDMI-compatible device (the “Source Device”) to a compatible computer monitor, video projector, digital television or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
HDMI version
2.1
Number of DisplayPort Ports
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is mainly used to connect a video source to a display device such as a computer monitor. In addition, it can also be used to transfer audio, USB, and other types of data.
2
DisplayPorts version
1.4
Number of Ethernet LAN ports (RJ-45)
Number of Ethernet LAN (RJ-45) ports (connection interfaces) in the device. Ethernet LAN ports (RJ-45) allow a computer to connect to Ethernet.
1
Microphone input
The socket where a microphone is connected to the device.
Line-out
Combined headphone/microphone jack
Design
Housing type
List of available types of chassis and their expandability, if applicable. 1 unit (1U) is 1.75 inches (4.45 cm).
Control tower
Volume (l)
The amount of a substance it contains.
27 l
Assisted Positioning
Where and how the product should be placed, e.g. indoor/outdoor, horizontal/vertical.
Vertical
Cable Lock Slot
Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.
Slot Type Cable Lock
Kensington
Product color
The color e.g. red, blue, green, black, white.
Black
Performances
Market positioning
In which product category the device can be classified on the market, e.g. camera phone.
Business
Motherboard Chipset
The chipset connects the microprocessor to the rest of the motherboard.
Intel W680
Audio chip
Realtek ALC897Q-CG
Audio system
System used to play music or speech.
High Definition Audio
Built-in speakers
The device has built-in speakers to generate sounds.
Number of speakers
The quantity of speakers included in/with the product.
1
Password
The computer, smartphone, etc. can only be used if the correct password has been entered. This makes it safer.
Password Protection Type
Turn On, Supervisor
Trusted Platform Module (TPM)
Product
The subcategory of the product.
Workstation
Software
Installed operating system
Type of operating system on one device, e.g. IOS on Apple devices, Android for other mobile devices.
Windows 11 Pro
Operating System Architecture
The way in which the operating system of a computer/smartphone (32-bit/64-bit) is set up.
64-bit
Operating system language
German
Energy
Power supply
The way in which the product is powered, e.g. battery, mains power via plug and cable.
750 W
Power Supply – Input Voltage
100 – 240 V
Power Supply – Input Frequency
The frequency of the electricity, usually measured in Hertz (Hz), which is supplied by the power supply. Mains electricity in many parts of the world is 50Hz.
50 – 60 Hz
80 Plus Certification
80 PLUS Platinum
Service conditions
Operating temperature
The minimum and maximum temperatures at which the product can be safely operated.
10 – 35 °C
Storage temperature range
The minimum and maximum temperatures at which the product can be safely stored.
-40 – 60 °C
Relative humidity in operation
20 – 80%
Storage humidity
10 – 90%
Operating height
0 – 3048 m
Height when stored
0 – 12192 m
Certificates
Certificates
RoHS
Sustainability
Sustainability Compliance
Sustainability certificates
TCO, ENERGY STAR, EPEAT Gold, ErP
Weight and dimensions
Width
Measure or dimension of an object from one lateral edge to another.
180 mm
Depth
The distance from the front to the back edge of an object.
370 mm
Height
Height of the product
415 mm
Weight
Weight of the goods without packaging (net weight). If possible, the net weight including standard accessories and deliveries will be indicated. Please note that manufacturers sometimes give an overly commercial interpretation of the product weight without taking into account the weight of accessories and/or accessories.
13.6 kg
Scope of delivery
Mouse included
A mouse is included with this product.
Mouse connectivity
Wired
Keyboard included
A keyboard is included.
Keyboard connectivity
Wired
